FWG06 Air Cleaner Assembly, G068023 - G068023

Move your mouse over the image or click to enlarge

Donaldson

# G068023

FWG06 Air Cleaner Assembly, G068023

$633.75
$551.09 excl. GST
Adding to cart… The item has been added

Out of stock

Shipping: Available for immediate dispatch Contact your local branch for availability
PickUp:

Contact your local branch for availability

Store availability

Contact your local branch for availability

Next Day Delivery*

1 Year Warranty

Safety Approved

Need help or advice?

Call 0508 677 704 or Visit Instore

SKU:
G068023

PRODUCT INFORMATION

  • Overall Length = 423.2 mm (16.66 inch)
  • Inlet Diameter = 63.5 mm (2.50 inch)
  • Body Diameter Maximum = 165 mm (6.50 inch)
  • Outlet Diameter = 57.2 mm (2.25 inch)
  • Body Length = 264.7 mm (10.42 inch)
  • Rated Flow LR = 3.1 m³/min (109 cfm)
  • Rated Flow MR = 3.6 m³/min (127 cfm)
  • Rated Flow HR = 4 m³/min (141 cfm)
  • Restriction LR = 14.71 mbar (5.91 inch H2O)
  • Restriction MR = 19.61 mbar (7.87 inch H2O)
  • Restriction HR = 24.52 mbar (9.84 inch H2O)

Part No

G068023

Brand

Donaldson
