Hand Control Valves

#372/060/022/0

Door Control Valve 4/3 Way

Calculated Volume (dm³) = 0.83232 Comments = ETS Distance between holes = 80x27.4 mm Electrical connection = 3x 3-Pole to fit 6.3 DIN 46247 Max. operating pressure = 10.0 bar Mounting = 2x Ø 5.2 mm Nominal diameter = 4.0 mm Port thread 11 = M12 x 1...

#ABC284726

Dash Valve PP1 W/Button 1/8" Ports

-

#ABC287280

Dash Valve PP7 Style

-

#ABC248502

Knob, Yellow PP-1 Pull\Parking

-

#463/036/016/0

WABCO 3/2 Directional Control Valve

Actuation = Turn Actuation angle = 90° Calculated Volume (dm³) = 0.275 Max. operating pressure = 10.0 bar Mounting = M28 x 1.5 Nominal diameter = 4.0 mm Port thread 1 = M16 x 1.5 Port thread 2 = M16 x 1.5 Port thread 3 = Tappet Product category =...

#ABC287600/1

Dash Valve PP1 W\Button 1/4" & 1/8" Ports Dash Valve PP1 W\Button 1/4" & 1/8" Por...

-

#110300

Lever Control Tailgate Open-Close

A versatile manually operated lever valve used in a wide variety of applications. Toggles side to side to open or close. Inlet Port = 1/8'' Outlet Port = 1/8''

#13Y

Knob Yellow

-

#13

Knob Black - Ctrl Valve

-

#99600BL

S/Brake Cab Valve (Locking)

Commonly used as dash valve inside tractor or truck. Automatically shuts-off when inlet pressure drops below indicated psi.

#110587

Air Suspension Pilot Valve

This valve is typically used to deflate air suspension ride bags when the trailer is parked. It exhausts the delivery line when the pilot pressure is released. Pressurizing the pilot allows supply to flow to the delivery port. NPT Port Size = 3/8'' All

#99600

Auto Shut Off Valve

Commonly used as dash valve inside tractor or truck. Automatically shuts-off when inlet pressure drops below indicated psi. Name Plate = 806 Knob = 13 Inlet Port (NPT) = 1/4'' Outlet Port (NPT) = 1/4'' Exhaust Port (NPT) = 1/8'' Shut Off Pressure = 30...
