Part No
190-037-002
Brand
VDO
Illumination Output
Integrated 12V backlight for night visibility
Operating Temperature
-30°C to +85°C
Range
-60 to +60 Amps
Terminals
Heavy-duty threaded posts for secure high-current connections
Type
Gauge Type = Ammeter with internal shunt
Voltage
12V (illumination only; gauge is voltage-independent)
Installation (Hole) Diameter and Outside diameter
52 mm - 2 1/16 Inch en 59.25 mm - 2 1/3 Inch
Installation Depth
67.5 mm
Locking Height with Spinlock Nut
Not available
Locking Height with Bracket
0.5 mm - 8 mm
Flushmount
None
