Spring Brake 2424 L\S

Superior Power Spring Technology; Advanced powder coating process; Resists corrosion and fatigue

Double O-ring Centerseal; Two o-rings for positive sealing and plastic bearings for long life

World Class Diaphragm; High quality rubber compound, resistant to heat and cold; Superior flexibility even at -40°F

Rugged Service Housing; 9 gauge steel, powder coated Orange Alert® Stroke Indicator

Self-piloting Dust Shield

Sizes to fit all drum brake applications

Stroke Type = Long

Available Stroke = 2.50", 64mm

A (Length from mounting bracket to end of Spring Housing) = 9.3", 235mm

B (Length of Piggyback) = 6.8", 172mm

C (Dimension at rolled Spring Housing flange) = 7.5", 191mm

D (Dimension at Service Clampband) = 9.4", 239mm

J (Pushrod Length from face of Service Housing) = 10.00"

Weight = 17.3 lbs. , 7.8 kg.
