Filtration

#P164596

Hydraulic Filter Cartridge, P164596

Seal Material = Nitrile Outer Diameter = 78.7 mm (3.1 inch) Inner Diameter = 43.78 mm (1.72 inch) Length = 324 mm (12.76 inch) Overall Length = 327.7 mm (12.9 inch) Efficiency Beta 1000 = 7 micron Collapse Burst = 13.8 bar (200 psi) Style =...

#P171544

Hydraulic Cartridge, P171544

Outer Diameter = 95 mm (3.74 inch) Inner Diameter = 41 mm (1.61 inch) Length = 250 mm (9.84 inch) Efficiency Beta 200 = 18 micron Efficiency Beta 1000 = 23 micron Bypass Valve = Yes Bypass Valve Setting LR = 1.5 bar (21.8 psi) Collapse Burst = 10 bar...

#P171530

Hydraulic Filter Cartridge, P171530

Outer Diameter = 70 mm (2.76 inch) Inner Diameter = 29 mm (1.14 inch) Length = 128 mm (5.04 inch) Efficiency Beta 2 = 90 micron Bypass Valve = Yes Bypass Valve Setting LR = 1.5 bar (22 psi) Collapse Burst = 10 bar (145 psi) Style = Cartridge Series =...

#P171533

Hydraulic Filter Cartridge, P171533

Outer Diameter = 70 mm (2.76 inch) Inner Diameter = 29 mm (1.14 inch) Length = 130 mm (5.12 inch) Efficiency Beta 2 = 7 micron Efficiency Beta 1000 = 23 micron Bypass Valve = Yes Bypass Valve Setting LR = 1.5 bar (22 psi) Collapse Burst = 10 bar (145...

#P171537

Hydraulic Filter Cartridge, P171537

Outer Diameter = 95 mm (3.74 inch) Inner Diameter = 41 mm (1.61 inch) Length = 202 mm (7.95 inch) Efficiency Beta 1000 = 11 micron Bypass Valve = Yes Bypass Valve Setting LR = 1.5 bar (22 psi) Collapse Burst = 10 bar (145 psi) Style = Cartridge Series =...

#P171543

Hydraulic Filter Cartridge, P171543

Outer Diameter = 95 mm (3.74 inch) Inner Diameter = 41 mm (1.61 inch) Length = 250 mm (9.84 inch) Efficiency Beta 200 = 9 micron Efficiency Beta 1000 = 11 micron Bypass Valve = Yes Bypass Valve Setting LR = 1.5 bar (22 psi) Collapse Burst = 10 bar (145...

#P171570

Hydraulic Filter Cartridge, P171570

Outer Diameter = 140 mm (5.51 inch) Inner Diameter = 65.5 mm (2.58 inch) Length = 203 mm (7.99 inch) Efficiency Beta 2 = 17 micron Bypass Valve = Yes Bypass Valve Setting LR = 1.5 bar (22 psi) Collapse Burst = 10 bar (145 psi) Style = Cartridge Media...

#P165877

Hydraulic Filter Spin-On, P165877

Outer Diameter = 129 mm (5.08 inch) Thread Size = 1 1/2-16 UN Length = 169.16 mm (6.66 inch) Gasket OD = 128 mm (5.04 inch) Gasket ID = 120.9 mm (4.76 inch) Efficiency Beta 1000 = 23 micron Style = Spin-On Series = W023, HBK05, SP50/60, SP80/90,...

#P170310

Hydraulic Filter Spin-On, P170310

Outer Diameter = 79.5 mm (3.13 inch) Thread Size = 2-12 UN Length = 140.2 mm (5.52 inch) Gasket OD = 79.5 mm (3.13 inch) Gasket ID = 47 mm (1.85 inch) Efficiency Beta 1000 = 11 micron Style = Spin-On Series = HMK03 Disclaimer: Product name information...

#P171602

Hydraulic Filter Spin-On, P171602

Outer Diameter = 95.5 mm (3.76 inch) Thread Size = 3/4 BSP/G Length = 144.2 mm (5.68 inch) Gasket OD = 71.8 mm (2.83 inch) Gasket ID = 62 mm (2.44 inch) Efficiency Beta 1000 = 11 micron Style = Spin-On Media Type = Synthetic Primary Application = UCC...

#P171616

Hydraulic Filter Spin-On, P171616

Outer Diameter = 126 mm (4.96 inch) Thread Size = 1 1/4 BSP/G Length = 179 mm (7.05 inch) Gasket OD = 107 mm (4.21 inch) Gasket ID = 97 mm (3.82 inch) Efficiency Beta 2 = 27 micron Style = Spin-On Series = SP50/60, SP80/90, SP100/120 Media Type =...

#P171621

Hydraulic Filter Spin-On, P171621

Outer Diameter = 126 mm (4.96 inch) Thread Size = 1 1/4 BSP/G Length = 227.2 mm (8.94 inch) Gasket OD = 107 mm (4.21 inch) Gasket ID = 97 mm (3.82 inch) Efficiency Beta 2 = 27 micron Style = Spin-On Media Type = Cellulose Primary Application =...
