PRODUCT INFORMATION
- Magnetic core drill with large depth of feed, therefore suitable for use of core drills, spiral drills and countersinks
- Magnetic base with high holding power permits working on vertical surfaces and overhead
- Robust Metabo marathon motor with internal wiring for long service life
- Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
- Clockwise/anti-clockwise rotation with thread cutter
- Durable two-speed gearbox with oil bath lubrication for ideal speeds
- Integrated coolant container for easy to dose internal cooling of the core drill
- Bright LED light for easy alignment in poor light conditions
- Swarf protection can be fixed without tools and protects the user from metal shavings and tool contact
- Protective circuit starts motor only if the magnet is activated
- Overload protection: protects the motor from overheating
- Restart protection: prevents unintentional start-up after power supply interruption
- Lockable slide for comfortable tool change
- Handle for easy carrying and lifting
- Resistant mains cable (5 m) with rubber shroud
Part No
MAG50Brand
MetaboCable length
5 m / 16 ftOutput Power
620 WTorque Capacity Nm
90 / 50 NmPackaging Dimensions
0.43m Width x 0.57m Depth x 0.22m HeightGross Weight (kg)
19.80No-load Speed
100 - 250 / 200 - 450 rpmSound pressure level
79 dB(A)Rated input power
1200 WSpeed at rated load
250 / 450 rpmDrilling in metal
2.5 m/s²Tool holder
Morse taper MK 2 / Weldon shaft 19 mm (3/4'')Max. drill-Ø with core drill
50 mm / 2 ''Max. drill-Ø with spiral drill
20 mm / 3/4 ''Maximum drilling depth
50 mm / 2 ''Thread cutting
M 16Max. depth of feed
160 mm / 6 5/16 ''Max. magnetic holding force
12250 NDimensions of the magnet base
90 x 190 mm // 3 9/16 x 7 1/2 ''Height carriage lowest position
457 mm / 18 ''Height carriage topmost position
610 mm / 24 ''Write a Review
