Part No
4653
Brand
Hella
Maximum Current
12V 5000A For Up to 10 Seconds / 24V 2500A For Up to 10 Seconds
Mounting
22mm diameter opening. Up to 6mmØ bolts
Terminals
2 x 10mm Studs
Protection
IP X4 (Protection against water splashing)
Note
Switch not designed for Marine applications. Recommended to be mounted in dry area.
Maximum load
12/24V - 2500A for 10 seconds / 600A for 2 minutes
Maximum Continuous Load
12/24V - 100A continuous at a maximum ambient temperature of 60°C with 50mm2 lead connected with ring-type terminals.
Termination
2x 10mm studs (Max Torque 10±1Nm)
