PRODUCT INFORMATION
J.W. Speaker’s LED Model 93 lights are the new standard for 90mm lights, providing a drop-in replacement or pedestal mounts for original equipment manufacturers (OEMs), up-fitters, vehicle fleets, and individuals looking for the best-performing LED lights. The headlight offers many applications for a variety of vehicles suited for agriculture, automotive, construction, industrial, material handling, mining, motorcycle, off-road 4×4, railroad, specialty vehicles, and truck and bus.
Features:
- Drop-in replacement for standard 90mm lights
- 100% ECE & DOT compliant 90mm lights for legal on-road use
- Meets the tough criteria for IP67 and IP69K for the best protection from dust and water ingress
- Our re-designed die-cast aluminum housing features a sealed integrated connector to meet the harsh demands of transportation and municipal applications
- Pedestal mount brackets can be positioned at 90° intervals for maximum mounting flexibility, all while maintaining pattern integrity and legality
- Choose from industry-standard 90mm 3-point mounts for 1.5mm or 3mm thick mounting plates, and single or double light pedestal mounting brackets, that come with all necessary hardware for a seamless installation
Part No
0553091Brand
JW SpeakerCurrent Draw
1.97A @ 12V DC (Low Beam). 0.98A @ 24V DC (Low Beam)Voltage
Operating Voltage = 10-31V DCRed Wire
PositiveBlack Wire
NegativeInput Voltage
12-24V DCRaw Lumen Output
1,910Effective Lumen Output
575Candela Output
18,500Nominal LED Color Temperature
5000 KWrite a Review
